EVA Forming Machine Single Station
High Production Output up to 40 pairs/hour
350 Ton Clamping Force for reliable Moulding
Precision Temperature Control for consistent EVA products
Compact Vertical Design for efficient floor-space utilization
Get Best Price
Contact our team for machine specifications, pricing and availability.
Features
- PRODUCTION: 50-80 PAIR
- Station size: 560x800mm
- Clamping force: 370 ton
- Casting iron piston with chrome
- Cylinder size: 480mm
Description
The Single Station EVA Forming Machine is designed for efficient production of EVA soles, footwear components and other EVA products. Its vertical clamping configuration requires comparatively less floor space while providing effective moulding performance.
The machine incorporates a controlled heating arrangement and hydraulic system to achieve consistent processing conditions. Its versatile mould compatibility allows manufacturers to produce different designs and sizes of EVA products.
It is suitable for ladies' and gents' footwear soles, EVA slippers, toy tyres and other EVA products. Available product information specifies a production capacity of up to 80 pairs per hour.
|
Parameter |
Specification |
|
Machine Type |
Single Station EVA Forming Machine |
|
Production Capacity |
40 pairs/hour |
|
Station Size |
560 × 810 mm (22inches × 32 inches) |
|
Station Opening |
430 mm |
|
Clamping Force |
350 Ton |
|
Clamping Pressure |
120 Bar |
|
Hydraulic Pump Displacement |
120 LPM |
|
Pressure Pump Motor |
5 HP / 960 RPM |
|
Pressure Release Motor |
2 HP / 1440 RPM |
|
Electrical Heater |
20 × 1.0 kW |
|
Machine Floor Area |
915 × 2185 × 2185 mm |
|
Machine Weight |
2800 kg (Approx.) |
|
Station |
Single |
|
Application |
EVA Soles & Footwear Products |
