EVA FORMING MACHINE SINGLE STATION
EVA Forming Machine
Technical Specification
| Mould Clamping Unit | |
|---|---|
| Production Capacity | 80 pairs / hour |
| Station Size | 560 X 760 mm |
| Station Opening | 430 mm each |
| Clamping Force | 150 Ton |
| Clamping Pressure | 120 Bar |
| Hyd Pump Displacement | 120 lpm |
| Motor for Pressure Pump | 5 HP / 960 rpm |
| Motor for Pressure Release | 2 HP / 1440 rpm |
| Electrical Heater | 12 X 1.5 kw |
| Floor Area of Machine | 915 X 2185 X 2185 |
| Weight of Machine | 3500 kg |
Features
- RAM EVALITE - I is designed for making EVA soles for ladies and gents footwear, and extensively used in toy
industry for making Toy Cycle Tyres and other EVA product of different colours and size. - Sturdy design and simplicity in operation.
- Machine has vertical clamping hence uses very less space.
- Mould Space : It is easy to match with various kind of mould and reduces limitations of mould design.
- Temperature controlled by three temprature controllers: Gives perfection in maintaining the melt Temp. with least
variation. - Ergonomically designed and inter changeability.
